Nokia 8DG63207AA S13X100R Universal 100G MUX Card

Introduction
The Nokia 8DG63207AA, also known as the S13X100R, is a fully tested, refurbished 100 G coherent MUX/Transponder card for the Nokia 1830 Photonic Service Switch (PSS). Designed for carriers, data centres, and cloud network providers, this high-performance module supports flexible WDM aggregation and wire‑speed Layer 1 encryption, making it an ideal solution for modern service networks. Sourced from PICS Telecom's extensive inventory of refurbished networking equipment, it's ready to plug-and-play into 1830 PSS chassis to boost transport capacity with reliable, cost-effective performance.

Key Features & Benefits

• ✨ 100 G Coherent Tunable Port – Full C‑band tunability for adaptable fiber transport

• 🔄 Multi‑Rate Support – Handles 10G, 40G, and 100G client services on one universal card

• 🔐 Layer 1 AES‑256 Encryption – Secure high-speed transport for sensitive enterprise traffic

• 🔄 Integrated OTN Switching – Efficient grooming with 1G granularity across services

• ⚡ High Density & Low Power – Powered by Nokia’s PSE‑2c for efficiency and scalability

• 🛠️ Protection & Maintenance Tools – Built‑in FEC, PRBS, wavetracker, OMSP and O‑SNCP

Ideal For

• 📡 Backbone and metro DWDM transport

• ☁️ Data centre interconnect (DCI) applications

• 🔒 Secure enterprise or government networks

• 🔁 Service aggregation & grooming in universal carrier networks

Specifications at a Glance

• Part Number: 8DG63207AA

• Module Name: S13X100R (Universal 100 G Card)

• Network Port: 1× 100 G coherent WDM, full C‑band, PDM‑QPSK

• Client Ports:
  • CFP4/QSFP28: 100 GigE/OTU‑4
  • 2× QSFP+: 40 GigE/OTU‑3
  • 10× SFP+: 10 GigE, 8/10/16 G FC, OTU‑2, OC‑192/STM‑64

• FEC: SD‑FEC (25%), HD‑FEC

• Switching: Integrated OTN with groomable ODU0/1/2

• Encryption: AES‑256 Layer 1 (S13X100E variant with license)

• Power Consumption: 145 W (uplink/add‑drop) / 155 W (muxponder full client load)

• Form Factor: Full‑height, single slot in 1830 PSS chassis

• Environmental: 5 °C–40 °C normal, –5 °C–50 °C short, 5%–85% humidity

• Protections: O‑SNCP, OMSP/OLP, OPSA, OPSB

• Management: G.709 latency measurement, wavetracker/PRBS, OTN PM

• Compliance: UL/CSA 60950‑1, NEBS GR‑63, CE, RoHS, WEEE

Conclusion
Bring power, flexibility, and security to your optical layer with this Nokia 8DG63207AA (S13X100R), available refurbished and tested through PICS Telecom. Ideal for boosting DWDM core and metro networks, this modular router component fits directly into the 1830 PSS system to support scalable, encrypted, multi-rate transport. Visit www.picstelecom.com or marketplace.picstelecom.com to request a quote today — and contact PICS Telecom for help selecting the right unit for your deployment.
